Features:
1. Applying heat pipe technology to
obtain higher efficiency of heat dissipation, lighter of aluminum housing.
2. Design of module aluminum housing can
improve horizontal heat convection to prevent driver casing overheating and
protect the driver working under normal temperature.
3. Certificate approved LED
explosion-proof light in Asia area.
4.LED chip:
Epistar/Bridgelux/Cree/Philips.
5.Power supply: Mean well.
6. DIALUX simulation available.
|
Model
NO:
|
HB220-W150
|
Housing
Color
|
Silver/Black
|
|
Wattage
(w)
|
155±10W
|
IP
Rating ;
|
IP54/IP65
|
|
Lumens
(LM)
|
14250LM
|
Certification
|
CE,ROHS
,TUV,PSE，UL，DLC，CCC
|
|
Power
Fact (PF)
|
＞0.9
|
Warranty
(Years)
|
3
|
|
Beam
Angle (°)
|
45/90/120DEG
|
N.W.:
(KG)
|
5.12
|
|
OP.
Frequency (Hz./kHz)
|
50-60HZ
|
G.W.:
(KG)
|
6.00
|
|
Input
Voltage Range (V)
|
90-277VAC
|
Packing
Dimension（MM）
|
320*320*410
|
|
Luminous
Efficiency (LM/W)
|
85-100LM/W
|
Quantity
/ Carton( PCS)
|
1PCS
|
|
Color
Rendering Index (CRI)
|
＞70
|
Working
Environment
|
-30-40C
|
