Features:
1.Module lens design make the lamp with well suited lighting distributing
2.Cree LEDs, Mean well driver
3.Installation angle -90~+90 deg is adjustable
4. Dialux simulation service provided.
|
Model NO:
|
PL345-W080
|
Housing Color
|
Black
|
|
Wattage(W)
|
80W
|
IP Rating;
|
IP65
|
|
Lumens(LM)
|
7200LM
|
Certification
|
ETL ,DLC
|
|
Power Fact(PF)
|
>0.9
|
Warranty(Years)
|
3
|
|
Beam Angel(°)
|
90*120DEG
|
N.W.: (KG)
|
6.8
|
|
OP.Frequency(HZ./kHZ)
|
50-60HZ
|
G.W.: (KG)
|
7.4
|
|
Input Voltage Range(V)
|
85-265VAC
|
Packing Dimension
|
590*395*115
|
|
Luminous Efficiency(LM/W)
|
85-95
|
Quantity / Carton( PCS)
|
1PCS
|
|
Color Rendering Index(CRI)
|
>70
|
Working Environment
|
-35-45°
|
