Features:
1.) 1.Structured LED arrays mounted on metal core circuit for optimized light photometric distribution .
2.85*135°precision refractive optical lens designed for various applications
3.Powder coated, minimum 2.0 mil thickness.
4.LED brand :Samgung
5.Driver :Meanwell
6.Dialux simulation service provided
Model NO: | FF390-W20 | Housing Color | Grey or white |
Wattage (w) | 23±4W | IP Rating ; | IP65 |
Lumens (LM) | 1950LM | Certification | CE,ROHS |
Power Fact (PF) | ＞0.9 | Warranty (Years) | 3 |
Beam Angle (°) | 85x135DEG | N.W.: (KG) | 1.5 |
OP. Frequency (Hz./kHz) | 50-60HZ | G.W.: (KG) | 2 |
Input Voltage Range (V) | 85-265VAC | Packing Dimension(MM) | 518*312*414 |
Luminous Efficiency (LM/W) | 75-80LM/W | Quantity / Carton( PCS) | 6PCS |
Color Rendering Index (CRI) | ＞70 | Working Environment | -35-45C°
|
